Carbon dioxide laser marking machine
Basic information
商品名稱： 二氧化碳激光打標機
商品編號： 二氧化碳激光打標機
上架時間： 2015-05-21
適用材料： 打標的材料主要有竹木制品、陶瓷、紙張、布料皮革、有機玻璃、環氧樹脂、亞克力、不飽和聚酯樹脂等非金屬材料。
適用行業： 工藝禮品、有機玻璃、服裝皮革、木頭紙張、食品包裝、電子元器件、PCB、柔性線路板、陶瓷基片、半導體、晶體玻璃、塑料連接器、硅橡膠按鍵、SMD元件以及其他各種材料上的圖文標刻。
Product details
Trade name: Carbon dioxide laser marking machine
Product No.: Carbon dioxide laser marking machine
On sale time: 2015-05-21
Applicable materials: Bamboo and wooden products, ceramics, paper, cloth, leather, organic glass, epoxy resin, acrylic, unsaturated polyester resin, and other non-metallic materials.
Application: Gifts, organic glass, leather clothing, wood, paper, food package, electric appliance, PCB, flexible circuit board, ceramic substrate, semiconductor, crystal glass, plastic connector, SMD element, and other materials.
The product adopts American sealed-off RF excited CO2 laser.
High-speed scanning galvanometer adopts imported high-performance lasers with accurate precision, stable performance, and high speed. It can realize long-term stable and reliable operation, is easy to operate. Control software adopts Windows engineering interface, and it is compatible with Coreldraw.
Technical parameters
| Model |
WH-C30 |
|
Laser Type |
Imported metal packaging RF CO2 laser |
|
Cooling Mode |
Air-cooled or water-cooled |
|
Marking Mode |
Plane / cylinder |
|
Beam Expanders |
3-8times(optional) |
|
Marking Area |
100mm*100mm,175mm*175mm |
|
Maximum Laser Power |
30W |
|
Optical maser wavelength |
10.6um |
|
Minimum Line Width |
0.10mm |
|
Marking Line Speed |
≤7000mm/s |
|
Repeat Positioning Accuracy |
±0.01mm |
|
Engraving Depth |
≤3mm |
|
Minimum Characters |
0.40mm |
|
Pulse Frequency/Laser Repetition Rate |
≤25KHZ |
|
Dimensions (L x W x H) |
700mm*750mm*1500mm |
|
Weight |
Net weight:100kg |
Samples:
.jpg)
